MiniAMP LED touch/radio PWM dimmer with PIR sensor, 1 channel, 12-24V DC 5A, incl. radio push button
In stock
Article number
114597
| Product description | MiniAMP LED touch/radio PWM dimmer with PIR sensor, 1 channel, 12-24V DC 5A, incl. radio push button |
|---|---|
| Article number | 114597 |
| GTIN-EAN | 9009377083181 |
| Special features | Receiver with 6-way distributor (MiniAMP female socket) and 1m connection cable, wire cross-section 0,5mm² (MiniAMP male plug), max. distance between touch button and receiver: 10m, motion detection radius: 1-3m, switches off automatically 45 seconds after the last movement, a CR2032 3V button cell battery for the touch button with PIR sensor is included, a screw-on holding magnet is included. Only install and connect when voltage-free! |
| Nominal voltage | 12 - 24 V DC |
| Protection class | IP20 |
| Housing material | Plastic |
| Weight in gramm | 68 |
| Length in mm | 60,0 |
| Width in mm | 50,0 |
| Height in mm | 10,0 |
| Guarantee in years | 2 |
